TAURUS
Exterior wall light with dark sky optic
Information downloads
| Order code | Description | lm | W | lm/W | kg | A (mm) | B (mm) | C (mm) |
|---|---|---|---|---|---|---|---|---|
| TAU80NW | 6W - 4000K | 800 | 6 | 133 | 3.20 | 295 | 220 | 165 |
| TAU180NW | 13W - 4000K | 1800 | 13 | 138 | 3.20 | 295 | 220 | 165 |
| TAU300NW | 24W - 4000K | 3000 | 24 | 125 | 3.20 | 295 | 220 | 165 |
CITY WP
CONTACT US
Product features
- High performance optic for maximum spacing and distribution
- Maximum of 15m spacing, at 3m mounting height
- Dark sky optic to reduce upward light output with less than 2% ULOR
- Choice of 3 lumen outputs
- Photocell option also available
- Up to 138 lumens per Watt efficacy
- 50,000 hours lifetime (L80/B20)
Construction
- Die-cast aluminium body finished in grey (RAL 9006)
- Integral driver
- Supplied as standard with neutral white (4000K) LED
To specify
Die-cast aluminium wall light as per Tamlite TAURUS range
Installation notes
Fixed via rear mounting plate and wired via cable entry
Vision options
PC - Photocell
D - Dimmable DALI
M3 - 3 hours integrated emergency
A3 - Emergency self test
D3 - DALI self test
B - Black (RAL 9005)
