SOLO Track
Mains Single circuit track system
Information downloads
| Order code | Description | lm | W | lm/W | kg | A (mm) | B (mm) | c (mm) |
|---|---|---|---|---|---|---|---|---|
| T2400 | 2400mm track | - | 0 | - | 1.3 | 2445 | 35 | 18 |
| T600 | 600mm track | - | 0 | - | 0.34 | 615 | 35 | 18 |
| T1200 | 1200mm track | - | 0 | - | 0.64 | 1205 | 35 | 18 |
| T1800 | 1800mm track | - | 0 | - | 0.94 | 1835 | 35 | 18 |
Product accessories
SOLO CONNECTORS
SOLO END CAPSRelated products
I LINE 3 CIRCUIT TRACK
2020 TS SPOT
MINI SPOT
EUROPA
TRIO
Product features
Construction
To specify
Installation notes
Body options
- The Tamlite Solo single circuit system has an unobtrusive profile and includes a wide range of accessories for a variety of configurations
- Luminaires can be positioned at any point along a track length and secured with a simple twist and lock action
- Sections are supplied complete with two stop ends
- Available in 4 colour finishes
Construction
- Extruded aluminium body
- Each section supplied with dead-ends
- (*T2400 Only available in white and black)
To specify
Aluminium 230V single circuit track system as per Tamlite SOLO range
Installation notes
Surface fix via centre fixing hole
Body options
ALUM - Matt aluminium
B - Black (RAL 9005)
PB - Polished brass
W - White
